TB-9636 PLASTIC SERIES HIGH STRENGTH UV ADHESIVE

Product ID: 2593

Hits: 197

Company: Guangzhou top-bond environmental technology Co.,LTD

Release Time:2018-09-28 14:05:02

Keywords: light cure adhesive   /   engineering adhesive   /   Plastic adhesive

Inquiry    Favorite

Five Advantages Of Products

  • Low odor
  • Safety and environmental protection
  • Fast solidification without air bubbles
  • High bonding strength
  • Don't send white

Product Details

TOP-BOND  Product 9636 is a single component, medium viscosity, fast curing UV adhesive designed for bonding PVC and polycarbonate to itself and to a variety of other surfaces (such as PC/ PMMA/ PS/ PE /PET ). The product cures in seconds upon exposure to ultraviolet radiation of 365 nm to form an impact resistant bond which exhibits excellent resistance to prolonged humidity or water immersion.



TYPICAL PROPERTIES OF UNCURED MATERIAL

Chemical Type               Acrylate

Appearance                 Transparent amber liquid

Viscosity @ 25, mPa.s       4000±1000



Surface Cure Time

This is the time required to achieve a tack free surface.

Tack free time, s           15s



TYPICAL PROPERTIES OF CURED MATERIAL

(Cured 40 seconds @ 100 m W/cm2 using a high pressure mercury light source)



Physical Properties

Coefficient of thermal expansion,

@ 25℃, /                   160 x 10-6

80 to 120, /                200 x 10-6

Hardness (Shore D),             53

Water absorption,

24 hrs @ 25, %               1.8

Glass transition temperature     50

Tensile strength, N/mm2

PVC to PVC                    80

(Cured 40s @ 100mW/cm2, 365nm UV)



GENERAL INFORMATION

It is necessary to mix round the product before using it.Eye irritant; irritate to skin and skin sensitizer. Contain acrylic. In case of eye contact, flush with water for at least fifteen minutes; get medical attention. Wash with plenty of soap and water after skin contact.

Excessive or repeated skin contact may cause skin irritation and skin sensitizer. If skin reaction occurs, discontinue use and consult a physician.



Storage :

KEEP MATERIAL AWAY FROM CHILDREN.

Maximum shelf life may be obtained when product is stored in a cool, dry location at a temperature between 10°C to 26°C

TO PREVENT CONTAMINATION OF UNUSED PRODUCT, DO NOT RETURN ANY PRODUCT TO ITS ORIGINAL CONTAINER.



Pack

250ml or 1000ml



Note:

The data contained herein are furnished for information only and are believed to be reliable.

IF YOU HAVE ANY QUESTIONS PLEASE CONTACT GUANGZHOU TOP-BOND ENVIRONMENTAL TECHNOLONGY CO.LTD.
